95%-99.98% AZ80A Extruded Magnesium Alloy Bar Rod Billet for Electronics , Machinery Parts
Details:
Name: magnesium alloy bar,dissolvable magnesium bar.
Specification: Ø50mm,Ø60mm,Ø70mm,Ø80mm,Ø90mm,Ø100mm…..Or customized according to customer requirements.
AZ80A magnesium alloy is an alloy composed of magnesium and other elements added as the base. Its characteristics are: low density (about 1.8g/cm3 magnesium alloy), high specific strength, large specific modulus of elasticity, good heat dissipation, good shock absorption, greater impact load capacity than aluminum alloy, resistance to organics and alkali corrosion it is good. The main alloying elements of AZ80A are aluminum, zinc, manganese, cerium, thorium and a small amount of zirconium or cadmium.
| Hilbo magnesium alloy material Co., Ltd. |
| Quality Inspection Report |
| NO:JB/MS03-151-1236 |
| Model | Specifications | Process | Furnace No. | Chemical Composition (%) | Low power test |
| Al | Zn | Mn | Fe | Si | Cu | Ni | Mg | Low power | Surface quality | Size |
| | Ø80*1000 | Extrussion | 9850 | 8.5 | 0.60 | 0.3 | 0.005 | 0.1 | 0.05 | 0.005 | Balance | OK | OK | OK |
| |
AZ80A
H112 |
| Magnesium alloy bar | |
Tensile strength
Rm /Mpa | Yield strength 0.2%
Mpa | Elongation at break % |
| | 295 | 190 | 5 |
| | Conclusion :Passed inspection |
Magnesium Alloy Chemical Composition:
| Model | chemical component(%) |
| Type | Mg | Al | Zn | Mn | Si | Fe | Cu |
| AX31B | residual | 2.5-3.5 | 0.60-1.4 | 0.20-1.0 | ≤0.08 | ≤0.003 | ≤0.001 |
| AZ61A | | 5.8-7.2 | 0.40-1.5 | 0.15-0.50 | ≤0.10 | ≤0.005 | ≤0.005 |
| AZ80A | | 7.8-9.2 | 0.20-0.80 | 0.12-0.50 | ≤0.10 | ≤0.005 | ≤0.005 |
| AZ91D | | 8.5-9.5 | 0.45-0.90 | 0.17-0.40 | ≤0.08 | ≤0.004 | ≤0.001 |
Product Advantages:
- Dissolves even at minimal electrolyte concentrations (from 1%) and any temperature.
- The degradation by-product is a fine powder that does not interfere with production.
- Any size available.
Performance test data:
| No. | Model | Test condition | Dissolution rate
mg/(cm2*h)) | Strength of extension(MPa) | Yield strength(MPa) | Elongation
(%) | Hardness
(HB) |
| 1 | HB006 | 93℃/3%KCl | 50-70 | ≥370 | ≥260 | ≥2.5 | ≥90 |
| 2 | HB006A | 93℃/3%KCl | 50-70 | ≥310 | ≥220 | ≥6.0 | ≥75 |
| 3 | HB008 | 93℃/3%KCl | 40-60 | ≥400 | ≥300 | ≥4.0 | ≥100 |
| 4 | HB008B | 93℃/3%KCl | 40-60 | ≥370 | ≥270 | ≥5 | ≥100 |
| 5 | HB008C | 93℃/3%KCl | 40-60 | ≥310 | ≥220 | ≥15 | ≥85 |
| 6 | HB012 | 93℃/3%KCl | 40-60 | ≥400 | ≥300 | ≥3.0 | ≥100 |
| 7 | HB011 | 93℃/3%KCl | 15-35 | ≥420 | ≥300 | ≥3.0 | ≥100 |
| 8 | HB016 | 93℃/3%KCl | 35-55 | ≥280 | ≥180 | ≥15 | ≥60 |
| 9 | HB017 | 93℃/3%KCl | 40-50 | ≥200 | ≥140 | ≥17 | ≥55 |
| 10 | HB018K | 50℃/0.84KCl | 50-70 | ≥240 | ≥170 | ≥12 | ≥55 |
| 11 | HB018 | 50℃/0.84KCl | 30-50 | ≥230 | ≥170 | ≥12 | ≥55 |
| 12 | HB010 | 93℃/3%KCl | 15-35 | ≥190 | ≥120 | ≥30 | ≥45 |
| 13 | HB022 | 43℃/0.05%KCl | 50-60 | ≥300 | ≥200 | ≥5.0 | ≥75 |
| 14 | HB023 | 43℃/0.05%KCl | 20-40 | ≥280 | ≥200 | ≥7.5 | ≥65 |
| 15 | HB024 | 43℃/0.05%KCl | 50-70 | ≥260 | ≥220 | ≥5 | ≥60 |
| 16 | HB013A | 43℃/0.05%KCl | 80-100 | ≥260 | ≥230 | ≥3.5 | ≥75 |
| 17 | HB025 | 50℃/0.84%KCl | 90-110 | ≥275 | ≥200 | ≥12 | ≥65 |
| 18 | HB026 | 93℃/3%KCl | 20-40 | ≥450 | ≥350 | ≥3.0 | ≥110 |
| 19 | HB808 | 50℃/0.84%KCl | 50-70 | ≥370 | ≥260 | ≥3.0 | ≥100 |
| 20 | HB019 | 50℃/0.84KCl | 45-65 | ≥230 | ≥180 | ≥12.0 | ≥55 |
| 21 | HB055 | 93℃/3%KCl | 130-150 | ≥220 | ≥160 | ≥12.0 | ≥55 |
| 22 | HB035 | 93℃/3%KCl | 50-100 | ≥100 | ≥60 | ≥42.0 | ≥35 |
| 23 | HBMM6 | 50℃/0.84%KCl | 70-100 | ≥260 | ≥230 | ≥10.0 | ≥60 |
| 24 | HBMM7 | 50℃/0.84%KCl | 90-120 | ≥270 | ≥240 | ≥9.0 | ≥65 |
| 25 | HBMM8 | 93℃/3%KCl | 100-150 | ≥280 | ≥250 | ≥5.0 | ≥65 |
Advantage of Hilbo Company:
Full range of product types, Ensure production capacity
We ave advanced die-casting, extrusion, forging, rolling, casting processing production line and precision testing equipment. Can produce a variety of types of magnesium alloy and magnesium alloy products, and developed a high-strength magnesium alloy extruded sheet. Through the purification of ordinary magnesium, magnesium can be raised up to 99.99% of high purity.
Cost advantage
Magnesium alloy casting production can customized as your requirement. the technical process is great, extrusion production required for a variety of bar, no need to purchase from abroad, extrusion molding products is easy molding, low energy consumption, saving production costs.
Workshop:
Our product and technical advantages:
1. Professional&advanced magnesium alloy casting technology.
2. We increase the elongation of magnesium alloy plate much better.
3. We make the crystal size of magnesium alloy plate more uniform.
4. We make the size difference of magnesium alloy plates much smaller.
5. The flatness of our magnesium alloy plate can reached 0.0001mm after our special hot-pressing process.
6. We accept customized magnesium alloy plate with thickness range from Imm to 200mm.
7. Advanced testing&inspection equipment.
8. Excellent after-sales service
Testing Equipment
Certificate:
We have attained ISO9001 and ISO14001 certificates, Standardize and improve the enterprise quality management system.
FAQ:
Q: How can I get the price?
A: We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
Q: Can I buy samples placing orders?
A: Yes. Please feel free to contact us.
Q: What is your lead time?
A: It depends on the order quantity and the season you place the order.Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
Q: What is your payment term?
A: This is negotiable. Usually T/T, 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q: What is the shipping method?
A: It could be shipped by sea, by air or by express (EMS, UPS, DHL,TNT, FEDEX and etc).Please confirm with us before placing orders.
